Model: YGX-SD200 Two-dimensional small range force sensor
Features and Applications
Small range
High resolution and high precision
A maximum axial force of 20N
Capacity : 500mN
Dimensions（mm）：
Specification:
|
|
Fx
|
Fz
|
|
Capacity
|
0.5N
|
0.5N
|
|
Resolution
|
10mN
|
10mN
|
|
Nonlinearity
|
0.19%F.S
|
0.08%F.S
|
|
Hysteresis
|
0.12%F.S
|
0.12%F.S
|
|
Zero Balance
|
0.15%F.S
|
0.23%F.S
|
|
Repeatability
|
0.24%F.S
|
0.09%F.S
|
|
Precision
|
0.31%F.S
|
0.01%F.S
|
|
Excitation
|
≥5V
|
|
Operation temp range
|
-10~ +40℃
|
|
Safe overload
|
150%F.S
|
|
Material
|
Aluminum alloy
|
